Cooler Master MasterBox 520 Mid Tower Gaming Case - Black

Cooler Master MasterBox MB520 Mesh ARGB Mid Tower ATX Gaming Case - Black

REMOVABLE TOP PANEL

The top panel is entirely removable for improved access and easy installation of cooling solutions such as fans and radiators.

SCREWLESS & TOOL-FREE TG SIDE PANEL

The tempered glass side panel is secured with pins for easy removal, facilitating quick, easy installation.

(RE)MOVABLE HDD CAGE

The HDD cage is completely (re)movable for improved access during assembly and system upgrades.

UPGRADED REMOVABLE DUST FILTER BRACKET

The bottom dust filter bracket is robust and locked sturdily in place during travel, remaining easy to remove for cleaning purposes.

RICH CONNECTIVITY

The I/O panel comes with a USB 3.2 (Gen 2) Type-C port, a USB 3.2 (Gen 1) Type-A port, and one 3.5mm (audio + mic) headset jack.

HARDWARE COMPATIBILITY

MasterBox 520 Mesh is natively compatible with ITX, M-ATX and ATX motherboards.

E-ATX motherboards, such as SSI-CEB models, are compatible with dimensions up to 12" x 10.7".

Specifications:-

• Materials - Exterior : Mesh

• Materials - Left Side Panel : Tempered Glass

• Dimensions (L x W x H) : 499 x 210 x 498mm (Incl. Protrusions), 430 x 210 x 479mm (Body Size)

• Volume : 43L

• Motherboard Support : Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12" x 10.7" motherboards, may impact cable management feature)

• Expansion Slots : 7

• 3.5" Drive Bays : 2

• 2.5" Drive Bays : 3

• I/O Panel : 1x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2 Type-C, 1x 3.5mm Headset Jack (Audio+Mic), 1x Reset/ARGB button

• Included Accessories : ARGB Fans Hub

• Pre-installed Fans - Front : 3x CF120 ARGB

• Fan Support - Top : 3x 120mm, 2x 140mm

• Fan Support - Front : 3x 120mm, 2x 140mm

• Fan Support - Rear : 1x 120mm

• Radiator Support - Top : 120mm, 140mm, 240mm, 280mm, 360mm, (recommended maximum thickness -55mm)

• Radiator Support - Front : 120mm, 140mm, 240mm, 280mm, 360mm

• Radiator Support - Rear : 120mm

• Clearance - CPU Cooler : 165mm/6.49"

• Clearance - PSU : 200mm, (Recommended up to 170mm)

• Clearance - GFX : 410mm/16.1"

• Dust Filters : Bottom, Front, Top

• Power Supply Support : ATX

• Series : MasterBox Series

• Size : Mid Tower
