MORE AIR MORE CONTROL
PERFORMANCE & STYLE
The MA610P is for enthusiasts and gamers to push their
systems to the limit. Exceptional cooling performance is a must to keep it
running stable and at max speeds. The MA610P is also stylishly design to match
the precision engineered components in your build. It even comes with a dual
RGB fans and controller for you to change the your lighting without
limitations.
PRECISION ENGINEERED HEATSINK
Cooler Master's aluminum fin craftmanship is second to none.
Optimized fin stacked distance between each layer is based on stringent airflow
tests from our labs.
ACCELERATED AIR PRESSURE TO BEAT THE HEAT
The 2 x MasterFan 120 Air Balance RGB accelerates removal of
heat with the 'Push and Pull'. Cold air is drawn into the MA610P heatsink from
one side to cool to cool off the heat generated from the CPU. Hot air is then
quickly pulled out from the other side to ensure the CPU operates at maximum
effiency.
45% MORE CONTACT WITH CDC 2.0
The Continuous Direct Contact 2.0 Technology increases the
surface area of the copper base by 45% to maximize the contact and removal heat
from the CPU. The total of 6 heatpipes, the MA610P is able to maximize TDP
capacities.
PLAY WITH COLORS USING THE RGB LED CONTROLLER
A wired RGB LED controller is included with the MA610P to
change the RGB lighting anytime you want (no software needed). Switch it up
depending on your mood, the possibilities are not limitless.
EASY INSTALLATION
The easy install mounting kit ensures hassle-free
installation. Universal retention brackets are compatible with latest Intel and
AMD socket CPU.
Product Name |
MasterAir MA610P |
Model |
MAP-T6PN-218PC-R1 |
CPU Socket |
Intel® LGA 2066 / 2011-v3 / 2011 / 1151 / 1150 / 1155 /
1156 / 1366 / 775 socket |
Dimensions |
122.3 x 112.8 x 166.5 mm (4.8 x 4.4 x 6.5") |
Heat Sink Dimensions |
116 x 60 x 158 mm (4.5 x 2.4 x 6.2") |
Heat Sink Material |
6 Heat Pipes / Direct Contact / Aluminum Fins |
Heat Sink Weight |
616g (1.35lb.) |
Heat Pipe Dimensions |
Ø6 mm |
Fan Dimensions |
120 x 120 x 25 mm (4.7 x 4.7 x 1") |
Fan Speed |
600 – 1,800 RPM (PWM) ± 10% |
Fan Air Flow |
53.38 CFM (Max) |
Fan Air Pressure |
1.65mm H2O (Max) |
Fan MTTF |
40,000 hours |
LED Color |
RGB ready |
Fan Noise Level |
35 dBA (Max) |
Fan Connector |
4-Pin |
Fan Rated Voltage |
12 VDC |
Fan Rated Current |
0.30 A |
Fan Safety Current |
0.37 A |
Fan Power Consumption |
4.44 W |
