Can deliver fast 100+ FPS performance in the world's most popular games, discrete graphics card required
6 Cores and 12 processing threads, bundled with the AMD Wraith Stealth cooler
4.2 GHz Max Boost, unlocked for overclocking, 19 MB cache, DDR4-3200 support
For the advanced Socket AM4 platform
AMD StoreMI Technology
A fast and easy way to expand and accelerate the storage in a desktop PC with an AMD Ryzenâ„¢ processor.
AMD "Zen 3" Core Architecture
The fastest cores in the world for PC gamers.
AMD Ryzenâ„¢ VR-Ready Premium
For the best possible VR experiences, AMD offers select Ryzenâ„¢ VR-Ready Premium processors.
Platform : Desktop
Market Segment : Mainstream Desktop
Product Family : AMD Ryzenâ„¢ Processors
Product Line : AMD Ryzenâ„¢ 5 Desktop Processors
Consumer Use : Yes
Regional Availability : Global, China, NA, EMEA, APJ, LATAM
Former Codename : "Cezanne"
Architecture : "Zen 3"
# of CPU Cores : 6
Multithreading (SMT) : Yes
# of Threads : 12
Max. Boost Clock : Up to 4.2GHz
Base Clock : 3.6GHz
L1 Cache : 384KB
L2 Cache : 3MB
L3 Cache : 16MB
Default TDP : 65W
Processor Technology for CPU Cores : TSMC 7nm FinFET
CPU Compute Die (CCD) Size : 180mm²
Package Die Count : 1
Unlocked for Overclocking : Yes
CPU Socket : AM4
Socket Count ; 1P
Supporting Chipsets : X570
X470
X370
B550
B450
B350
A520
Windows 8.1 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
USB Type-C® Support : Yes
Native USB 4 (40Gbps) Ports : 0
Native USB 3.2 Gen 2 (10Gbps) Ports : 4
Native USB 3.2 Gen 1 (5Gbps) Ports : 0
Native USB 2.0 (480Mbps) Ports : 0
Native SATA Ports : 2
PCI Express® Version : PCIe 3.0
Native PCIe® Lanes (Total/Usable) : 24/20
Additional Usable PCIe Lanes from Motherboard : AMD X570 16x Gen 3
AMD X470 2x Gen 3
AMD X470 8x Gen 2
NVMe Support : Boot, RAID0, RAID1, RAID10
System Memory Type : DDR4
Memory Channels : 2
Max. Memory : 128GB
System Memory Subtype : UDIMM
System Memory Specification : Up to 3200MHz
Max Memory Speed : 2x1R DDR4-3200
2x2R DDR4-3200
4x1R DDR4-2933
4x2R DDR4-2667
Graphics Capabilities
Product IDs
Product ID Boxed : 100-100000457BOX
Product ID Tray : 100-000000457
Key Features
Supported Technologies
AMD StoreMI Technology
AMD "Zen 3" Core Architecture
AMD Ryzenâ„¢ VR-Ready Premium
