AMD Ryzen 7 9800X3D Desktop Processor

AMD RYZEN 7 9800X3D - 8 Core AM5 Gaming Processor

Harness the ultimate gaming edge with AMD Ryzen™ 7 9800X3D Processor. Enjoy faster gaming with 2nd gen AMD 3D V-Cache™ technology for low latency.

For gamers looking to upgrade their socket AM5 motherboards, the Ryzen 7 9800X3D 4.7 GHz Eight-Core AM5 Processor is ready to let you boost frame rates and graphics settings in the latest triple-A titles. Like other X3D CPUs, the 9800X3D features AMD 3D V-Cache technology designed to boost gaming performance by positioning its 96MB of ultra-fast stacked L3 cache close to the cores. Built upon Zen 5 architecture and providing eight-core, sixteen-thread processing, the 9800X3D can achieve a 4.7 GHz base clock speed, with a max boosted clock of 5.2 GHz. Other advanced technologies that are supported include PCIe 5.0 for high-end graphics cards and SSDs, and up to 192GB of speedy DDR5-5600 memory.

AMD EXPO

Ryzen-optimized AMD EXPO (Extended Profiles for Overclocking) profiles provide a user-friendly method to overlocking your DDR5 memory when using the Ryzen 7 9800X3D with your socket AM5, increasing software load speeds and boosting overall gaming performance.

Additional Features

• Unlocked to support CPU overclocking

• 120W TDP (Thermal Design Power) with no active cooling provided

• Integrated Radeon graphics

• Increased CPU speed with Precision Boost 2

Specifications

• Name : AMD Ryzen™ 7 9800X3D

• Family : Ryzen

• Series : Ryzen 9000 Series

• Form Factor :  Desktops , Boxed Processor

• Market Segment :  Enthusiast Desktop

• AMD PRO Technologies : No

• Consumer Use : Yes

• Regional Availability : Global

• Former Codename : Granite Ridge AM5

• Architecture : Zen 5

• # of CPU Cores :  8

• Multithreading (SMT) : Yes

• # of Threads : 16

• Max. Boost Clock :  Up to 5.2 GHz

• Base Clock :  4.7 GHz

• L1 Cache : 640 KB

• L2 Cache : 8 MB

• L3 Cache : 96 MB

• Default TDP : 120W

• Processor Technology for CPU Cores : TSMC 4nm FinFET

• Processor Technology for I/O Die : TSMC 6nm FinFET

• Package Die Count : 2

• Unlocked for Overclocking : Yes

• AMD EXPO™ Memory Overclocking Technology : Yes

• Precision Boost Overdrive : Yes

• Curve Optimizer Voltage Offsets : Yes

• AMD Ryzen™ Master Support : Yes

• CPU Socket :  AM5

• Supporting Chipsets :  A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850

• CPU Boost Technology : Precision Boost 2

• Instruction Set : x86-64

• Supported Extensions :  AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64

• Thermal Solution (PIB) : Not Included

• Recommended Cooler : Liquid cooler recommended for optimal performance

• Max. Operating Temperature (Tjmax) : 95°C

• *OS Support : Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit

Connectivity

• Native USB 3.2 Gen 2 (10Gbps) Ports : 4

• Native USB 2.0 (480Mbps) Ports : 1

• PCI Express® Version : PCIe® 5.0

• Native PCIe® Lanes (Total/Usable) : 28 , 24

• NVMe Support :  Boot , RAID0 , RAID1 , RAID5 , RAID10

• System Memory Type : DDR5

• Memory Channels : 2

• Max. Memory : 192 GB

• System Memory Subtype : UDIMM

• Max Memory Speed

                                2x1R

                                DDR5-5600

                                2x2R

                                DDR5-5600

                                4x1R

                                DDR5-3600

                                4x2R

                                DDR5-3600

• ECC Support : Yes (Requires mobo support)

Graphics Capabilities

• Graphics Model : AMD Radeon™ Graphics

• Graphics Core Count :  2

• Graphics Frequency : 2200 MHz

• USB Type-C® DisplayPort™ Alternate Mode : Yes

Supported Technologies

•     AMD EXPO™ Technology , AMD Ryzen™ Technologies
