AMD Ryzen 9 9950X3D Desktop Processor

Key Features:

• 16 Cores and 32 Threads
• 4.3 GHz Base Clock
• Zen 5 Architecture
• AM5 CPU Socket
• AMD Radeon™ Graphics Graphics Model

The ultimate 16-core desktop CPU with 2nd gen AMD 3D V-Cache™ Technology that can do it all with incredible performance for the most demanding gamers and creators.

Specifications

• Name : AMD Ryzen™ 9 9950X3D

• Family : Ryzen

• Series : Ryzen 9000 Series

• Form Factor : Desktops , Boxed Processor

• Market Segment :  Enthusiast Desktop

• AMD PRO Technologies :  No

• Regional Availability : Global

• Former Codename : Granite Ridge AM5

• Architecture : Zen 5

• # of CPU Cores : 16

• Multithreading (SMT) :  Yes

• # of Threads : 32

• Max. Boost Clock :  Up to 5.7 GHz

• Base Clock :  4.3 GHz

• L1 Cache : 1280 KB

• L2 Cache : 16 MB

• L3 Cache : 128 MB

• Default TDP : 170W

• Processor Technology for CPU Cores : TSMC 4nm FinFET

• Processor Technology for I/O Die : TSMC 6nm FinFET

• Package Die Count : 3

• Unlocked for Overclocking : Yes

• AMD EXPO™ Memory Overclocking Technology :  Yes

• Precision Boost Overdrive :  Yes

• Curve Optimizer Voltage Offsets : Yes

• AMD Ryzen™ Master Support : Yes

• CPU Socket : AM5

• Supporting Chipsets : A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850

• CPU Boost Technology : Precision Boost 2

• Instruction Set : x86-64

• Supported Extensions : AES , AVX512 , AVX2 , AVX , FMA3 , MMX-plus , SSE2 , SSE4.2 , SSE4A , SSE4.1 , SSE3 , SSSE3 , SSE , x86-64

• Thermal Solution (PIB) : Not Included

• Recommended Cooler : Liquid cooler recommended for optimal performance

• Max. Operating Temperature (Tjmax) : 95°C

• *OS Support : Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit

• Native USB 3.2 Gen 2 (10Gbps) : 4

• Native USB 2.0 (480Mbps) :  1

• PCI Express® Version : PCIe® 5.0

• Native PCIe® Lanes (Total/Usable) : 28 , 24

• NVMe Support :  Boot , RAID0 , RAID1 , RAID5 , RAID10

• System Memory Type :  DDR5

• Memory Channels :  2

• Max. Memory : 192 GB

• System Memory Subtype : UDIMM

• Max Memory Speed

                                2x1R
                                DDR5-5600
                                2x2R
                                DDR5-5600
                                4x1R
                                DDR5-3600
                                4x2R
                                DDR5-3600

• ECC Support : Yes (Requires mobo support)

• Graphics Model : AMD Radeon™ Graphics

• Graphics Core Count : 2

• Graphics Frequency : 2200 MHz

• USB Type-C® DisplayPort™ Alternate Mode :  Yes

• Product ID Boxed : 100-100000719WOF

• Product ID Tray : 100-000000719

• Supported Technologies : AMD EXPO™ Technology , AMD Ryzen™ Technologies
