SKU:90IG05P0-MU0410
QR Code : 1202388
In stock
AX1800 Dual Band WiFi 6 (802.11ax) Range Extender / AiMesh Extender for seamless mesh WiFi; works with any WiFi router.
Get Your Home Ready for WiFi 6 (802.11ax)
The growing number of connected personal and IoT devices has led to an overall increase in network density that is pushing the limits of the current WiFi standard. The latest 802.11ax standard provides future-proof technologies, higher network efficiency, faster WiFi speeds, greater coverage and improved battery life for connected devices, providing a significantly better networking experience for users.
*It requires 802.11ax-compatible devices to enjoy the benefits brought by 802.11ax WiFi standard.
Next-Gen WiFi Speed
RP-AX56 is a 2x2 dual-band WiFi 6 range extender that provides 80MHz bandwidth and 1024-QAM for dramatically faster wireless connections. With a total networking speed of about 1800Mbps — 574Mbps on the 2.4GHz band and 1201Mbps on the 5GHz band — RP-AX56 is 1.5X faster than 802.11ac 2x2 dual-band range extender .
Create and Extend Your AiMesh WiFi System
ASUS RP-AX56 is a WiFi 6 AiMesh extender and WiFi range extender that lets you easily expand your current wireless network to deliver powerful and seamless connectivity to every corner of your home. In addition to whole-home WiFi, when used with AiMesh routers, RP-AX56 can extend those AiMesh routers′features.
Incredibly Easy, but Incredibly Powerful
AiMesh is incredibly easy to use, but that doesn't mean it's not powerful. When it is part of an AiMesh network, RP-AX56 still provides comprehensive features and easy central control of all settings from the ASUS Router mobile app or ASUSWRT. So great features like AiProtection, QoS and Parental Controls work across the entire network, ensuring that no-one can bypass them by connecting to a different router. Just remember to always connect your highest-specification router to your internet service.
Seamless, Pain-Free WiFi
When used with AiMesh routers, RP-AX56 can create a single, whole-home WiFi network, so you don't have to switch networks as you move throughout your house. AiMesh keeps an eye on the signal strength to your device, and switches it seamlessly to another source if necessary. All you have to do is enjoy it! If you prefer separate network names for each frequency band, you can do that as well — AiMesh is designed to work the way you want!
One or Multiple WiFi Name, the Choice is Yours
When extending current AiMesh network, you can choose to keep only one WiFi name (SSID) for the entire home network for easier usage; or separate WiFi names so you can dedicate different WiFi band for different usage. For example, dedicate the 5GHz band to gaming devices with higher bandwidth needs and 2.4GHz band for normal usage.
Flexible Backhaul Connection with Router
RP-AX56 supports AP mode, so you can establish Ethernet backhaul with on-wall Ethernet jacks in your home to create a wired connection between the router and RP-AX56. This not only provides even more stable WiFi, but also dedicates the entire 2.4GHz and 5GHz bands to wireless devices for smoother connections.
Works Perfectly with Any WiFi Router
RP-AX56 is also a WiFi 6 range extender that works perfectly with virtually all WiFi routers, modems and cable routers/gateways on the market, so you don't have to worry if you do not have an AiMesh/ASUS router yet.
Easy Setup - Extend WiFi from Non-AiMesh Router
If you don‘t have an AiMesh router, setting up your RP-AX56 WiFi 6 range extender is still easy. It doesn't require messing with discs, or even a mouse and keyboard. You can use the ASUS Extender app to easily transfer your router's login information to RP-AX56 with just a few taps; or use the Pair buttons on RP-AX56 and your router for instant automatic setup.*
*Pair button setup and ASUS Extender app setup is not applicable when RP-AX56 is working with AiMesh routers.
Model Name : RP-AX56
Network Standard
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6
Product Segment
Data Rate
802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 1201Mbps
Antenna : Internal antenna x 2
Transmit/Receive
2.4GHz 2x2
5GHz 2x2
Operating Frequency
Ports
Button
Reset Button, WPS Button
LED Indicator
Package content
RP-AX56
Quick Start Guide
Product Weight (g)
AiMesh
AiMesh
AiMesh node
Router APP
Wireless
Wi-Fi Encryption : WPA3-Personal, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support
Administration
Operating mode : Range extender mode
Access point mode
Media bridge mode
Operating system : Windows 10
Windows 10 64-bit
Windows 8.1
Windows 8
Windows 7
Mac OS
Linux
Free OS upgrade
Dimension
