Cooler Master 750W 80 Plus Gold Full Modular Power Supply - Black

COOLER MASTER G Gold 750 V2 - 750W 80 Plus Gold ATX 3.1 Power Supply Unit - Black

Power Evolved

G Gold 750 V2

Power Evolved

Cooler Master presents the G Gold V2, the upgraded version of the G Gold featuring ATX 3.1 support, high temperature resilience, a quiet HDB fan, 80 Plus Gold efficiency, an embossed cable.

ATX 3.1 Support

Compliant with ATX 3.1 to fully support a peak power 1.5 times higher than the rated maximum wattage, the 750W unit is specially equipped with a 12V-2x6 cable, optimized for ideal compatibility with 40 series GPUs.

Embossed Cable

An embossed cable texture provides a softer and overall improved grip with a pleasing aesthetic.​

Quiet HDB Fan​

A hydrodynamic bearing fan delivers long-lasting quiet and effective cooling.​

Exceptional Efficiency

The G Gold V2 is certified to achieve more than 90% efficiency at typical loads.​​

High Temperature Resilience

A 40°C operating temperature allows for pushing your machine to the limits.​

*All performance stats confirmed in 25C ambient temperature testing.

Specifications

• Model : MPE-7502-ACAAG

• ATX Version : ATX 12V Ver. 3.1

• PFC : Active PFC

• Input Voltage : 100-240V

• Input Current : 10-6A

• Input Frequency : 50-60Hz

• Dimensions (L x W x H) : 140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch

• Fan Size : 120mm

• Fan Bearing  : HDB

• Efficiency : ≥90% @ Typical Load

• 80 PLUS Rating : 80 PLUS Gold

• ErP 2014 Lot 3 : Yes

• Operating Temperature : 0-40°C

• Power Good Signal : 100 - 150 ms

• Hold Up Time : >16ms

• MTBF : >100,000 Hours

• Protections : UVP / OVP / OPP / OTP / SCP

• Regulatory : cTUVus, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (Based on region's requests.)

• ATX 24 Pin Connectors : 1

• EPS 8 Pin / 4+4 Pin Connectors : 2

• SATA Connectors  : 6

• Peripheral 4 Pin Connectors : 3

• PCI-e 6+2 Pin Connectors  : 4

• Series : G Series

• 80 Plus Efficiency : Gold

• Modular : Non Modular

• Category : 500 to 750W

• Form Factor : ATX

• Watts : 750W
