COOLER MASTER V SFX 850W - 80 Plus Gold Gen 5.0 Fully Modular Power Supply Unit - Black

COOLER MASTER V SFX 850W - 80 Plus Gold Gen 5.0 Fully Modular Power Supply Unit - Black

V SFX Gold 850 ATX 3.0

Small But Mighty

Small But Mighty

As the leading SFX power supply design, the V SFX Gold offers a highly powerful unit in a space-saving, mini form factor.

Flexible Compatibility

With the included SFX-to-ATX bracket, the V SFX Gold ATX 3.0 can be used to power systems ranging from as small as a mini-ITX all the way up to E-ATX motherboards.

ATX 3.0 support & a durable 90-degree 12VHPWR cable

Includes ATX 3.0 support and a 90-degree 12+4pin (12VHPWR) PCIe 5.0 connector featuring higher electrical durability, lower temperatures, and improved safety.

80 PLUS Gold certified

The V SFX Gold is certified to achieve more than 90% efficiency at typical loads.

High-quality Japanese capacitors

Large, high-quality Japanese capacitors feature inmproved efficiency and reduced ripple noise.

Fully modular cabling

Modular cabling reduces clutter, increases airflow, and improves overall thermal performance.

Specifications

• Model : MPY-8501-SFHAGV-3XX

• ATX Version  : ATX 3.0, SFX 12V Ver. 3.42

• PFC  : Active PFC

• Input Voltage  : 100-240V

• Input Current : 12-6A

• Input Frequency : 50-60Hz

• Dimensions (L x W x H)   : 100 x 125 x 63.5 mm

• Fan Size  : 92mm

• Fan Bearing :  FDB

• Efficiency : 90% @ Typical Load

• 80 PLUS Rating  : 80 PLUS Gold

• ETA Rating : Gold

• LAMBDA Rating     Standard+

• ErP 2014 Lot 3 : Yes

• Operating Temperature :  0-50°C

• Power Good Signal  : 100 - 500 ms

• Hold Up Time : 16ms

• MTBF  : >100,000 Hours

• Protections : OVP, OPP, SCP, OCP, UVP, OTP, Surge and Inrush Protection

• Regulatory : TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, CB, UKCA

• ATX 24 Pin Connectors : 1

• EPS 4+4 Pin Connectors  :1

• EPS 8 Pin Connector  : 1

• SATA Connectors  : 2

• Peripheral 4 Pin Connectors  : 1

• PCI-e 6+2 Pin Connectors : 2

• 12VHPWR Connector : 1

• Series :  V SFX Series

• 80 Plus : Gold

• Modular :  Fully Modular

• Wattage : Above 750W
