CORSAIR Force Series MP600 Gen4 NVMe M.2 SSD(R-4,950MB/s,W-4,250MB/s)1TB

Corsair Force Series MP600 Gen4 PCIe X4 NVMe M.2 SSD – 1TB

PCIE 4.0 (GEN4) TECHNOLOGY

As a PCIe 4.0 SSD, the MP600 delivers incredible storage performance, delivering up to 10 times the sequential read and sequential write speeds of some SATA SSDs and up to 50 times the speed of some traditional HDDs. The MP600 is also fully backwards compatible with current PCIe 3.0 platforms

DISCLAIMER: Performance may vary based on system hardware and configuration.

LOWER TEMPERATURES, HIGHER PERFORMANCE

The MP600 is equipped with a high surface area aluminum heatsink, helping to maintain its performance even under heavy load.

HIGH-DENSITY 3D TLC NAND MEMORY

Provides an ideal mix of performance, endurance, and value to keep your drive performing at its best for years, with outstanding longevity up to 3,600TB Written*.

*Endurance varies by capacity.

M.2 2280 FORM FACTOR

Easily fits directly into your new AMD X570 chipset-based motherboard, freeing up drive space in your PC to provide better airflow and easier cable routing.

READY FOR RYZEN

CORSAIR is a proud launch partner for AMD's 3rd generation of Ryzen processors. The MP600 is engineered to help you get the full benefit of PCIe 4.0 speed right out of the gate with your new Ryzen-based PC.

Product Specifications

COMPATIBILITY

• Form Factor: M.2 SSD
• Supported PCIe Gen4 Platforms: X570
• Backward compatible with PCIe Gen3 Platforms: Intel ® 100, 200, 300, X99, X299 Chipsets, AMD Socket AM4 Platform, X399

TECHNICAL SPECIFICATIONS

• Endurance: 1,800 TBW
• TBW: 1800
• MTBF: 1,700,000 Hours
• DEVSLP: PS4 < 1.65mW
• Encryption: AES 256-bit Encryption
• Storage Temperature: -40 °C to +85 °C
• SSD Operating Temperature: 0 °C to +70 °C
• SSD Shock: 1500 G
• Storage Humidity: 93% RH (40 ° C)
• Operating Humidity: 90% RH (40 ° C)
• Vibration: 20Hz~80Hz/1.52mm, 80Hz~2000Hz/20G
• SSD Interface: PCIe Gen 4.0 x4
• SSD Max Sequential Read CDM: Up to 4,950MB/s
• SSD Max Sequential Write CDM: Up to 4,250MB/s
• Max Random Write QD32 IOMeter: Up to 600k IOPS
• Max Random Read QD32 IOMeter: Up to 680k IOPS
• Power Consumption active: 6.5W Average
• Power Consumption Inactive: 1.1W
• Form Factor: M.2 2280
• Dimension: 80mm x 23mm x 15mm
• Application Consumer: Client
