GIGABYTE NVIDIA GeForce RTX 5070 Ti WINDFORCE OC V2 16GB Graphics Card - Black

• Powered by the NVIDIA Blackwell architecture and DLSS 4
• Powered by GeForce RTX™ 5070 Ti
• Integrated with 16GB GDDR7 256bit memory interface
• WINDFORCE cooling system
• Reinforced structure

• CORE CLOCK : 2497 MHz (Reference: 2452 MHz)

GeForce RTX 50 Series - Game Changer! Powered by NVIDIA Blackwell, GeForce RTX 50 Series GPUs bring game-changing capabilities to gamers and creators. Equipped with a massive level of AI horsepower, the RTX 50 Series enables new experiences and next-level graphics fidelity. Multiply performance with NVIDIA DLSS 4, generate images at unprecedented speed, and unleash your creativity with NVIDIA Studio.

WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system features three 80mm unique blade fans, alternate spinning, 8 composite copper heat pipes, a copper plate directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.

UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.

3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.

ALTERNATE SPINNING
Reduce the turbulence of adjacent fans and increase airflow pressure.

GRAPHENE NANO LUBRICANT

Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.

LARGE COPPER PLATE & COMPOSITE COPPER HEAT PIPES
The large copper plate directly contacts the GPU, coupled with the composite copper heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.

Specifications:

• Graphics Processing: GeForce RTX™ 5070 Ti
• Core Clock : 2497 MHz (Reference: 2452 MHz)
• CUDA® Cores : 8960
• Memory Clock : 28 Gbps
• Memory Size : 16GB
• Memory Type : GDDR7
• Memory Bus : 256 bit
• Card Bus : PCI-E 5.0
• Digital max resolution : 7680 x 4320
• Multi-view : 4
• Card size : L=261 W=126 H=50 mm
• PCB Form : ATX
• DirectX : DirectX 12 API
• OpenGL : OpenGL 4.6
• Recommended PSU : 750W
• Power Connectors : 16 pin*1
• Output : DisplayPort 2.1b x3
• HDMI 2.1b x1
• Accessories
• 1. Quick guide
• 2. 1x 12V-2x6 to 2x PCIe 8pin adapter
