Intel Core Ultra 5 Processor 250K Plus

Key Features:

• Next‑Gen Platform Support: Compatible with Intel 800 Series Chipset‑based motherboards with LGA1851 Socket enabling PCIe 5.0/4.0 and high‑speed DDR5 memory (up to 7200 MT/s).

• Ultra‑Fast Boost Clocks: Reaches up to 5.5 GHz max turbo frequency for top‑tier responsiveness and performance

• Built for Enthusiasts: Unlocked for performance tuning when paired with Intel Z‑series chipsets, making it ideal for overclockers and power users.

• Robust Power & Thermal Design: Engineered with 125W base power and 250W max turbo power to sustain high‑intensity

Intel® Core™ Ultra 5 Processor 250K Plus. Featuring PCIe 5.0 & 4.0 support and DDR5 support, Intel® Core™ Ultra 5 Processors 250K Plus are optimized for gamers and productivity and help deliver high performance. Compatible with Intel® 800 Series Chipset-based motherboards. 125W Processor Base Power.

Intel Core Ultra 200S Plus CPUs

In this episode, we look at the chip layout of Intel Core Ultra 200S Plus series processors and break down what’s actually changed inside the architecture. From faster die-to-die links to improvements in the memory subsystem, these changes help reduce latency and improve gaming performance.

Overclocking
How Overclocking Really Works on Intel CPUs

In this video, we break down what overclocking can actually change inside the processor, and why memory, fabric, and ring frequencies matter as much as core clocks. If you’re a PC enthusiast or gamer who wants to understand the “why” behind overclocking, this one’s for you.

Fixing Overthreading in Games
Intel Application Optimization (APO)

If you’ve ever wondered why too many threads can be a bad thing, we break down what’s happening under the hood and how Intel APO improves workload efficiency.

Specifications

Essentials

• Product Collection : Intel® Core™ Ultra Processors (Series 2)

• Code Name : Products formerly Arrow Lake

• Vertical Segment : Desktop

• Processor Number  : 250K PLUS

• Overall Peak TOPS (Int8)  : 30

CPU Specifications

• Total Cores  : 18

• # of Performance-cores : 6

• # of Efficient-cores : 12

• # of Low Power Efficient-cores : 0

• Total Threads  : 18

• Max Turbo Frequency  : 5.3 GHz

• Performance-core Max Turbo Frequency  : 5.3 GHz

• Efficient-core Max Turbo Frequency  : 4.6 GHz

• Performance-core Base Frequency  : 4.2 GHz

• Efficient-core Base Frequency  : 3.3 GHz

• Cache  : 30 MB Intel® Smart Cache

• Total L2 Cache : 30 MB

• Processor Base Power  : 125 W

• Maximum Turbo Power  : 159 W

• Intel® Deep Learning Boost (Intel® DL Boost) on CPU  : Yes

• AI Software Frameworks Supported by CPU : OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN

• CPU Lithography  : TSMC N3B

• Supplemental Information : Marketing Status


• Embedded Options Available  : No

• Use Conditions  : PC/Client/Tablet, Workstation

Memory Specifications

• Max Memory Size (dependent on memory type)  : 256 GB

• Memory Types  : Up To DDR5 7200 MT/s

• Max # of Memory Channels  : 2

• ECC Memory Supported ‡  : Yes

GPU Specifications

• GPU Name‡  : Intel® Graphics

• Graphics Base Frequency  : 300 MHz

• Graphics Max Dynamic Frequency  : 1.9 GHz

• GPU Peak TOPS (Int8)  : 8

• Graphics Output  : eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL

• Xe-cores : 4

• Max Resolution (HDMI)‡  : 4096 x 2304 @ 60Hz (HDMI 2.1 TMDS)

• 7680 x 4320 @ 60Hz (HDMI 2.1 FRL)

• Max Resolution (DP)‡  : 7680 x 4320 @ 60Hz

• Max Resolution (eDP - Integrated Flat Panel)‡  : 3840 x 2400 @ 120Hz

• DirectX* Support  : 12

• OpenGL* Support  : 4.5

• OpenCL* Support  : 3

• H.264 Hardware Encode/Decode  : Yes

• H.265 (HEVC) Hardware Encode/Decode  : Yes

• AV1 Encode/Decode  : Yes

• Intel® Quick Sync Video  : Yes

• # of Displays Supported ‡ : 4

• Device ID : 0x7D67

• Intel® Deep Learning Boost (Intel® DL Boost) on GPU  : Yes

• AI Software Frameworks Supported by GPU : OpenVINO™, WindowsML, DirectML, ONNX RT, WebGPU

NPU Specifications

• NPU Name‡ : Intel® AI Boost

• NPU Peak TOPS (Int8)  : 13

• Sparsity Support : Yes

• Windows Studio Effects Support : Yes

• AI Software Frameworks Supported by NPU : OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN

Expansion Options

• Direct Media Interface (DMI) Revision : 4

• Max # of DMI Lanes : 8

• Intel® Thunderbolt™ 4  : Yes

• Scalability : 1S Only

• PCI Express Revision  : 5.0 and 4.0

• PCI Express Configurations ‡  : Up to 1x16+2x4, 2x8+2x4, 1x8+4x4

• Max # of PCI Express Lanes  : 24

Package Specifications

• Sockets Supported  : FCLGA1851

• Thermal Solution Specification  : PCG 2020A

• Max Operating Temperature  : 105 °C

• Package Size : 45 mm x 37.5 mm

Advanced Technologies

• Intel® Gaussian & Neural Accelerator  : 3.5

• Intel® Thread Director  : Yes

• Intel® Speed Shift Technology  : Yes

• Intel® Turbo Boost Technology ‡  : 2.0

• Intel® Hyper-Threading Technology ‡  : No

• Intel® 64 ‡  : Yes

• Instruction Set  : 64-bit

• Instruction Set Extensions  : Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

• Idle States  : Yes

• Enhanced Intel SpeedStep® Technology  : Yes

• Thermal Monitoring Technologies  : Yes

• Intel® Volume Management Device (VMD)  : Yes

Security & Reliability

• Intel vPro® Eligibility ‡  : Intel vPro® Enterprise

• Intel® Threat Detection Technology (TDT) : Yes

• Intel® Active Management Technology (AMT) ‡  : Yes

• Intel® Standard Manageability (ISM) ‡  : Yes

• Intel® Remote Platform Erase (RPE) ‡ : Yes

• Intel® One-Click Recovery ‡ : Yes

• Intel® Secure Key   : Yes

• Intel® Control-Flow Enforcement Technology  : Yes

• Intel® Total Memory Encryption - Multi Key : Yes

• Intel® AES New Instructions  : Yes

• Intel® Trusted Execution Technology ‡  : Yes

• Execute Disable Bit ‡  : Yes

• Intel® OS Guard : Yes

• Intel® Boot Guard  : Yes

• Mode-based Execute Control (MBEC)  : Yes

• Intel® Stable IT Platform Program (SIPP)  : Yes

• Intel® Virtualization Technology with Redirect Protection (VT-rp) ‡ : Yes

• Intel® Virtualization Technology (VT-x) ‡  : Yes

• Intel® Virtualization Technology for Directed I/O (VT-d) ‡  : Yes

• Intel® VT-x with Extended Page Tables (EPT) ‡  : Yes
