NZXT H7 Flow (2024) Mid Tower ATX Case - White

• Supports three bottom-mounted 120mm fans for direct GPU cooling while retaining a narrow mid-tower footprint.
• Comes equipped with three front-mounted 120mm fans for exceptional out-of-the-box cooling.
• High-performance mesh panels maximize airflow for both intake and exhaust, as well as filter dust.
• Supports up to 420mm radiators in the front and 360mm radiators in the top for powerful cooling potential.
• Intuitive cable management system with wide channels, built-in hooks, and included straps for easy routing.
• Capacity for up to 10 fans in total: 3 up top, 3 in front, 3 on bottom, and 1 in the rear.
• Conveniently access 2 x USB-A and 1 x USB-C ports located on the top panel.
• Tool-less access to the front, top, and side panels makes building and upgrading a breeze.

Inside the Box

• H7 Flow : 1
• F120Q Airflow Fan (pre-installed, case version) : 3
• Installation Accessories: 1
• Manual : 1

NZXT H7 FLOW (2024) Mid Tower ATX Case - White

The H7 Flow revolutionizes GPU cooling in a classic mid-tower form factor. Its vertical PSU layout allows space for 3 x 120mm bottom fans, offering efficient cooling without expanding the case footprint.

• Supports three bottom-mounted 120mm fans for direct GPU cooling while retaining a narrow mid-tower footprint.
• Comes equipped with three front-mounted 120mm fans for exceptional out-of-the-box cooling.
• High-performance mesh panels maximize airflow for both intake and exhaust, as well as filter dust.
• Supports up to 420mm radiators in the front and 360mm radiators in the top for powerful cooling potential.
• Intuitive cable management system with wide channels, built-in hooks, and included straps for easy routing.
• Capacity for up to 10 fans in total: 3 up top, 3 in front, 3 on bottom, and 1 in the rear.
• Conveniently access 2 x USB-A and 1 x USB-C ports located on the top panel.
• Tool-less access to the front, top, and side panels makes building and upgrading a breeze.

Dedicated GPU Cooling

Supports three bottom-mounted 120mm fans for direct GPU cooling in a narrow mid-tower footprint.

Out-of-the-Box Performance

Comes equipped with 3 x 120mm front-mounted fans for exceptional out-of-the-box cooling performance.

Optimized for Airflow

High-performance mesh panels maximize airflow for both intake and exhaust, as well as filter dust.

Large Radiator Support

Supports up to a 420mm radiator in front and 360mm radiator up top for max cooling potential.

Easily Manage Cables

Intuitive cable management system with wide channels, built-in hooks, and included straps for easy routing.

10-Fan Capacity

Capacity for up to 10 fans in total: 3 up top, 3 in front, 3 on bottom, and 1 in the rear.

Top I/O Ports

Conveniently access 2 x USB-A and 1 x USB-C ports located on the top panel.

Tool-less Panel Access

Tool-less access to the front, top, and side panels makes building and upgrading a breeze.

Specifications

Key Specs

• Motherboard Support : E-ATX (Up to 277mm), ATX, Micro-ATX, Mini-ITX
• Enclosure Type : Mid-Tower
• Case Material : SGCC Steel, Ultra-Clear Tempered Glass (White)

Dimensions

• Height (with feet) : 544 mm
• Width : 244 mm
• Depth : 468 mm
• Weight : 11.13 kg

Compatibility & Clearance

• CPU Cooler Height:Up to 185 mm
• GPU Length:Up to 410 mm
• PSU Length:Up to 200 mm
• Cable Management:Up to 34.5 mm
• Top Mounted 140mm / 280mm Radiator & Fan Combined Thickness:Up to 57 mm

Front I/O Ports

• USB 3.2 Gen 1 Type-A:2
• USB 3.2 Gen 2 Type-C:1
• Headset Audio Jack:1

Expansion Slots

• Standard:7
• Vertical:0

Drive Bays

• 2.5":2+2
• 3.5":2

Fan Support

• Front:3 x 120 mm / 3 x 140 mm (3 x F120Q included)
• Top:3 x 120 mm / 2 x 140 mm
• Rear:1 x 120 mm / 1 x 140 mm
• Filters:High-Performance Mesh

Radiator Support

• Front:Up to 420 mm
• Top:Up to 360mm
• Rear:Up to 140mm

Fan Specs

• Model:F120Q Airflow Fan (Case Version)
• Speed:1,350 ± 150 RPM
• Airflow:60.2 CFM
• Static:1.05 mm - H2O
• Noise:24.1 dBA
• Fan Connector:3-pin

General

• CM-H72FW-01 (White)
• UPC: 810074845564 (White)
• EAN: 5056547205519 (White)
