XIGMATEK VISION ARGB LED ATX Case - Black

• Smart Fan Control LCD Display Panel
• Traditional Fan Blade

                       Pre-installed on Rear Side

                       Pre-installed on MB & PSU Shroud Panel Side

• CPU Cooler Clearance up to 180 mm
• GPU Length Limitation up to 420mm
• Support GPU Vertical Installation
• 3 Tempered Glass Panel Design
• Superior Airflow and Ventilation Design
• SSD/HDD Mounting Flip Cover
• Bottom-Mounted Magnetic Dust Filter
• Side I/O Ports :

  • Power Button
  • HD Audio Jack
  • USB 3.0 x2
  • Type C

XIGMATEK VISION ARGB LED ATX Mid-Tower Case - Black

Vision (BK, EATX, U3x2 & Type C, 3PCS TG, 1PC G24A+6PCS G24A Reverse+ARGB LED Fan Control Panel)

3 Tempered Glass Panel Design

Superior Airflow and Ventilation Design

Traditional Fan Blade

• 800-2200 RPM PWM Fan Pre-installed on Rear Side

Reverse Fan Blade

• 800-2200 RPM PWM Fan Pre-installed on MB & PSU Shroud Panel Side

Smart Fan Control LCD Display Panel

Smart Fan Control LCD Display Panel User Guide

• Left Control Konb
• Rotate: RGB Light Display Control
• Short Press: RGB LED Speed Control
• Middle Control Knob
• Short Press: RGB Light On/Off
• Long Press: ARGB Motherboard SYNC Switch
• Right Control Knob
• Rotate: 4 Fan Speed Control (800/1200/1700/2200 RPM)

Support Motherboard up to E-ATX

Support ATX Back Plug Motherboard

• Supported Model:
• ASUS TX GAMING B760-BTF
• ASUS TUF GAMING Z790-BTF WIFI
• ROG MAXIMUS Z790 HERO BTF and more to come.

Fan Support

• MB: 120mm x3 or 140mmx3
• PSU Shroud: 120mm x3
• Rear: 120mm or 140mm x1
• SSD/HDD Mounting Bracket: 120mm x1

ARGB & PWM Hub

Radiator Support

• MB: 240/280/360
• (EATX MB Width ≤ 290mm)

PSU Limitation up to 220mm

CPU Cooler Clearance up to 180 mm

GPU Length Limitation up to 420mm

Support GPU Vertical Installation

SSD/HDD Mounting Bracket

• (Rear MB Panel) 3.5″ x1 or 2.5″ x2

SSD/HDD Mounting Flip Cover

• Option A:
• 3.5″ x3 or 3.5″ x2 & 2.5″ x1 or 3.5″ x1 & 2.5″ x2 or 2.5″ x3
  (SSD/HDD Mounting Bracket without 3.5″ HDD or 12cm Fan)
• SSD/HDD Mounting Flip Cover
  Option B:
  3.5″ x2 or 3.5″ x1 & 2.5″ x1 or 2.5″ x2
  (SSD/HDD Mounting Bracket with 3.5″ HDD or 12cm Fan)

SSD/HDD Mounting Flip Cover

Bottom-Mounted Magnetic Dust Filter

Side I/O Ports

• Power Button
• HD Audio Jack
• USB 3.0 x2
• Type C

Specifications

• Product Name : Vision
• Dimensions : 450x258x476mm (LxWxH)
• Fan Support : MB: 120mm x3 or 140mmx3

                                    PSU Shroud: 120mm x3

                                    Rear: 120mm or 140mm x1

                                    SSD/HDD Mounting Bracket: 120mm x1

• Drive Bays : SSD/HDD Mounting Bracket (Rear MB Panel)

                                3.5″ x1 or 2.5″ x2

                                SSD/HDD Mounting Flip Cover :

                                Option A:

                                3.5″ x3 or 3.5″ x2 & 2.5″ x1 or 3.5″ x1 & 2.5″ x2 or 2.5″ x3

                                (SSD/HDD Mounting Bracket without 3.5″ HDD or 12cm Fan)

                                Option B:

                                3.5″ x2 or 3.5″ x1 & 2.5″ x1 or 2.5″ x2

                                (SSD/HDD Mounting Bracket with 3.5″ HDD or 12cm Fan)

• CPU Cooler Clearance : 180mm
• Material : Steel
• Expansion Slots : 7 Standard Slots

                                            (Support GPU Horizontal or Vertical Installation)

• Motherboard Support : EATX

                                                    ATX (Support Back Plug)

                                                    Micro ATX

                                                    Mini ITX

• Power Supply : Standard PS2 ATX PSU
• Radiator Support : MB: 240/280/360

                                                (EATX MB Width ≤ 290mm)

• I/O Panel : USB3.0 x2

                                Type C

                                HD Audio

• PSU Length Limitation : 220mm
• GPU Length Limitation : 420mm
